The new high-voltage 22.8V 23000mAh pouch cell drone battery is assembled by JinBa Battery after years of technical precipitation and improvement with high quality and high performance high-voltage lithium cells. The nominal voltage of the cell is 3.8V, and the energy density reaches more than 200Wh/kg. At the same time, the problems of the UAV battery have been effectively improved, so that the drone has better working performance and efficiency.
Specs Of Gapowor 23000mAh 22.8V LiHv Pouch Cell UAV Battery
Configuration:6S1P
Balancer Connector Type:JST-XHR-7P
Capacity(mAh):23000
Balancer Wire Length(mm):65
Voltage(V):22.8
Connector Type:XT90-S / others
Discharge Rate:25C
Discharge Wire Length(mm):150
Height(±2mm):63
Max Burst discharge Rate (C):50
Width(±2mm):91
Wire Gauge:10#
Length(±5mm):208
Net Weight(±20g):2474
Other Capacity:40000mAh / 22000mAh / 17000mAh / 11000mAh
JinBa LiHv Pouch Cell UAV battery Features
Support 3C fast charging customization
300+ times cycle life
Higher and more stable discharge platform
Smaller internal resistance and better charging and
Discharging efficiency due to the stacking process
With complete battery product certifications
Lighter weight under the same specifications
Higher energy density of 275Wh/kg
Operating temperature range: -30℃～60℃
Support max. 3C discharge at -30℃
Perfect after-sales service
Applications
The 22.8V high-voltage version of 23000mAh soft pack lithium battery for drones is a product developed by JinBa Battery after years of technical experience and accumulation, and the improvement of technical process makes the manufacturing level have a very good improvement; at the same time, it makes the drone battery in energy energy density (range) and service life has been improved to a certain extent, which saves the partners of drone battery application and has greatly improved the working efficiency.
22.8V high-voltage version of 23000mAh soft pack lithium battery for UAV is widely used in aerial photography, traffic distribution, mapping, rescue, underwater, aerial survey, agriculture and other fields.
