Highlights
Features higher capacities for greater compatibility with more power-hungry devices, and the latest in USB-C Power Delivery capable of charging larger USB devices like laptops.
Includes pre-installed solar charging optimization module that functions as a maximum power point tracker (MPPT), resulting in up to 40% faster charge times.
With grade A BYD LiFePO4 lithium cells, known for stability and safety, monitored by a state-of-the-art battery management system thatprevents over-charge, over-current, and short circuiting.
Built in Multi safety protection that include short circuit, overload and over-temperture and error code reporting.
| MODEL | HBP18-1012 | HBP18-2024 | HBP18-3024 | |||||
|---|---|---|---|---|---|---|---|---|
| Inverter | ||||||||
| Rated power | 1000W | 2000W | 3000W | |||||
| Output voltage waveform | Pure sine wave | |||||||
| Output voltage regulation | 230Vac ±5% | |||||||
| Output frequency | 50Hz / 60Hz (±0.2Hz) | |||||||
| Peak efficiency | 90% | |||||||
| Nominal DC input voltage | 12Vdc (±0.3) | 24Vdc (±0.3) | 24Vdc (±0.3) | |||||
| Standby Consumption | < 25W | |||||||
| PV Input | ||||||||
| Max solar power input | 900W | 1800W | 1800W | |||||
| PV max charging current | 60A (±3A) | 60A (±3A) | 60A (±3A) | |||||
| Combined charging current | 70A (±4A) | 80A (±4A) | 80A (±4A) | |||||
| Max efficiency | 98.0% max | |||||||
| PV array open circuit voltage | 105VDC | 145VDC | 145VDC | |||||
| PV Array MPPT Voltage Range | 15~105V | 30~120VDC | 30~120VDC | |||||
| AC Input | ||||||||
| AC input voltage | 230Vac ±5% | |||||||
| Acceptable input voltage range | 90-280VAC | |||||||
| Nominal input frequency | 50Hz / 60Hz (Auto detection) | |||||||
| Transfer time | 10ms typical (UPS, VDE); 20ms typical (APL) | |||||||
| AC Charge | ||||||||
| Charging current @ Nominal input voltage | 10/20A (±4A) | 20A/30A (±4A) | 20A/30A (±4A) | |||||
| Charging Algorithm | 4-step (Li) | |||||||
| Output | ||||||||
| AC output | 230Vac | |||||||
| USB (5V 2.4A) | DC output*2pcs | |||||||
| USB (12V 1A) | DC output*1pcs | |||||||
| Lithium Battery | ||||||||
| Energy | 960Wh | 1280Wh | 1532Wh | 2560Wh | 6400Wh | 2560Wh | 3840Wh | 6400Wh |
| Nominal voltage | 12.8V | 25.6V | 25.6V | |||||
| Standard charging & discharge current | 50A | 50A | 50A | 100A | 50A | 50A | 100A | |
| Maximum continuous charging & discharge current | 100A | 100A | 100A | 200A | 100A | 100A | 200A | |
| Operation temperature | ||||||||
| Charge | 0~45℃ | |||||||
| Discharge | -10~60℃ | |||||||
| Dimension | ||||||||
| Product Size (LxWxH) (mm) | 379*254*498.5 | 379*254*498.5 | 351*300*538.5 | |||||
| Packing Size (LxWxH) (mm) | 467*342*670 | 467*342*670 | 439*388*690 | |||||
| Net Weight (kg) | / | 24 | 31 | / | / | / | 39.5 | / |
| Gross Weight (kg) | / | 35 | 42 | / | / | / | 55 | / |
