The 22.2V New Version of Gapowor Plus 10000mAh smart lipo battery pack for drones is a product developed by JinBa Battery after years of technical experience and accumulation, and the improvement of technical process makes the manufacturing level a very good improvement; at the same time, it makes the drone battery in energy density (range) and service life has got a certain extent, which helps our partners of drone battery application save cost and greatly improve the working efficiency.
Specs of Gapowor Plus 10000mAh UAV Smart Lipo Battery
Configuration:6S1P
Balancer Connector Type:JST-XHR
Capacity(mAh):10000
Balancer Wire Length(mm):/
Voltage(V):22.2
Connector Type:EC5
Discharge Rate:25C
Discharge Wire Length(mm):160
Height(±2mm):63
Max Burst discharge Rate (C):50
Width(±2mm):70
Wire Gauge:AWG#10
Length(±5mm):186
Net Weight(±20g):1517
Other Capacities:22000mAh / 16000mAh / 12000mAh
10000mAh Smart Drone Battery Gapowor Plus Features
Self-heating at low temperature
Health self-check function
Abnormal record function
Waterproof and dustproof function
History information storage function
Charge protection function
Communication protection function
Intelligent protection function
Fire protection function
Charging and discharging terminals available
Applications
10000mAh smart drone battery Gapowor Plus is mainly used in agriculture plant protection, security mapping, logistics and other medium and large drones.
Equipped with industry-standard JST-XHP-7 plug. Best suited to Freefly ALTA, DJI S800, S800EVO, Walkera QR X800, FreeFly CineStar 6, FreeFly CineStar 8, etc. It is suitable for all industry drones, such as aerial photography drones, agriculture spraying drones, mapping drones, cargo transportation drones, etc.
